Select the screw and cylinder align them so that the screw is in the middle of the cylinder now group them. Now bring out another cylinder make it 0.2"x0.2"x0.3" take the screw and turn it into a hole. Selecting both of them align them so that the screw is in the middle and adjust so that the bottom of the screw is flat on top of the cylinder, then group them (picture 2). Then take the other screw we still have out from earlier make a copy turn it so it stands upright. Start by bringing out a cylinder and make it 0.5"x0.5"x0.1". This step is when we make the tool that helps to take out the pegs. Continue the same step for the outer box also making holes directly it the center (picture 4). If done correctly, you should be able to see your peg hole from the outside (picture 3). Then select ONLY the cylinder and the box and group them. Make it a hole and align it in this same spot as the peg's hole. Finally, make another cylinder that is 0.3" wide and long then turn it 90 degrees. Select the second box and a peg hole aligning them so that the peg hole is in the middle, then move it back slightly so that it is flush with the inside of the box. Next, duplicate the peg hole made in the last step. Then, keeping them selected, group it all together.
Select both the screw, cylinder, and snap, and align it so that the screw is in the middle of both of them (picture 2). Make a duplicate of it and make it a hole.
WILD ROSE PUZZLE BOX 3D PRINT ISO
Next, bring out a ISO metric screw, shrink it to 0.15"x0.15"x0.2" then turn it 90 degrees. Now bring out a cylinder, turn it 90 degrees and then shrink it down to 0.2"x0.3x0.2. Shrink it down to 0.2" all around and turn it 90 degrees.
